Weather Proof Gauges

Weather Proof Gauges
Weather Proof Gauges
Product Code : 23
Product Description

Reckoning on our immense domain expertise, we have been betrothed in offering supreme grade Weather Proof Gauges that are suitable for corrosive environment and gaseous or liquid media. To manufacture these products, our professionals use excellent quality components and latest technology. The offered products are tested on several parameters by our quality controllers to ensure their flawlessness. To meet the varied needs of the clients, we are offering these Weather Proof Gauges at nominal costs.

Features:

  • High strength

  • compact design

  • Accurate functioning

  • Long working life



63MM Bottom Mounting

"Pointer" Weather proof gauges suitable for corrosive environment and gaseous of liquid media that will no obstruct the pressure system.

Construction Features

Dial Size

63mm, 100mm, 150mm & 250mm

Accuracy

+- 1% of full scale

Case & Bezel (IP-65)

SS 304 Snap Action Bayonet type

Movement

SS 304

Pressure Element

SS 316 (< 70 bar 'C' /Type/ > 70 bar Coil type)

Socket

SS 304/ SS316

Dial

Aluminium white painted with 270 degree black scale marking

Pointer

Al./ Brass, Zero adjustment/ Micro Zero Adjustment Pointer

Window

Toughened/ Safety glass

Blow Out Protection

63mm on top & 100 & 150mm on back side at 0.6 kg/cm2

Over Load Protection

125% of f.s.d. For < 150kg/cm2


115% of f.s.d. For > 150 kg/cm2

Joints

Argon arc welded

Mounting

Stem (Bottom), Surface, Panel Mounting, Flush Panel (Bracke Type)

Connection

1/4, 3/8, 1/2, BSP/NPT

Scale Range

Vacuum, Compound & Pressure up to 1400 kg/cm2

Optional Features

  • SS 316 Case & Bezel available on request
  • Ammonia (NH3), Oxygen (O2), Freon Scale available on request.
  • Eco Model in Carbon Steel & SS Case available on request.

Application

Chemical & Petrochemicals, Power generation, Pollution Control Equipment, Oil exploration and any other application requiring fine quality, long lasting, pressure measurement etc.
